Page 10
(Continued)
Description
Number
Active uplink or downlink (displays only during data transfer)
3
Data usage
4
Number of connected devices
5
Rear View
The following figure shows the rear view of the mobile router.
Figure 3. Mobile router rear view
Description
Number
TS9 connector 1
1
USB type A port
2
USB type C port
3
Ethernet port
4
TS9 connector 2
5
The mobile router rear panel includes the following ports and connectors:
•
USB type A port. Connect a USB storage device or charge a smartphone.
For information about USB storage devices, see
on page 57.
For information about charging a smartphone, see
Use the Mobile Router to Jump Boost Another Device
on page 24.
•
USB type C port. Connect the USB type-C cable that came in the package to recharge the battery or
for a tethered connection to a computer.
For more information about recharging the battery, see
Recharge the Battery From a Wall Socket
on
page 22 and
Recharge the Battery From a Computer USB Port
on page 23.
A tethered connection to a computer lets you access the mobile router from a web browser without a
WiFi connection. See
on page 17.
•
Ethernet port.You can connect an Ethernet device to this port and you can offload your mobile Internet
data. The Ethernet connection speed is about 500 Mbps.
Get Started
10
Nighthawk LTE Mobile Hotspot Router Model MR1100
