Key Digital 4x4 UHD 4K Multiview Presentation Matrix Switcher - Manual (Page 2)

521 East 3 rd Street Mt. Vernon, NY 10553 • www.keydigital.com
Rev 1.2 – Apr, 2022
2
Table of Contents
About KD-MLV4X4PRO 3
Quick Setup Guide 5
Connect 5
Configure 5
Control 8
Application Example 11
KD-MLV4x4Pro Connections and LEDs 11
KD-EXMLVRx Connections and LEDs 15
Front Panel Control & LCD 17
IR Remote Control 19
Web User Interface 20
TCP/IP and RS-232 Commands 23
Text Overlay 28
Video Processor Transition Times 29
Integrating with AV over IP Systems 30
Specifications 31
Warranty Information 32
Product Warnings & Safety Instructions 32
Quick Setup Guide
Please visit www.keydigital.com for the latest product documentation,
firmware, control drivers and software downloads. Product features and
specifications are subject to change without notice
Always follow the instructions provided in this Operating Manual.
