Specifications
Technical
•
Input (Each): 1 HDMI Connector, Type A, 19 Pin Female
•
Output (Each): 1 HDMI Connector, Type A, 19 Pin Female
•
Output (Each): Balanced/unbalanced line level audio on 6-pin terminal block. Drives 2VRMS line audio
input with a sampling rate of 192KHz
•
Output (each): TOSlink optical digital audio following SPDIF format (IEC 60958). Supports sampling rate
up to 192KHz
•
Video Bandwidth: TMDS bandwidth 10.2 Gbps
•
DDC Signal (Data): Input DDC Signal - 5 Volts p-p (TTL)
•
HDMI Video/Audio Signal: Input Video Signal - 1.2 Volts p-p
•
DDC Communication: EDID and HDCP Bi-directional buffering to Display and Source
•
Analog Audio Max Output Le vel: 4dBu on 150kΩ, DC coupling
•
Audio Bandwidth: 20Hz to 20kHz @ 0dBu
•
TND + Noise: 0.33% @0dBu @ 1kHz
•
Optical Max Output Level: 1Vpp on 75Ω, DC coupling
•
Wired IR: modulated IR signal input, 0-5V TTL or -10 to +10V
•
Power: 12V/5 (60W) AC Power Supply with Grounded, 2.1mm ID DC Power Jack with Screw In Type
General
•
Regulation: CE, RoHS, WEEE, EAC
• Product Dimensions (LxWxH): 17.24 x 10.78 x 1.73” (438 x 237.7 x 44mm)
•
Product Weight: Weight: 8.02 lbs / 3.64 kg
•
Packaging Dimensions (LxWxH): 19.69 x
14.72 x 5.12” (500 x 374 x 130mm)
•
Packaging Weight: 13.93 lbs / 6.32 kg
