Changing the window picture input mode
Remote Commander
r —
MUTING
1=]
SLEEP POWER
CH» FHEBE Tv/woeo SWAP PIP
□ gg □ Q
CH- POStnOW AUDIO OFF
TV/VIOEO
000 a
1
Press PIP to display a window picture.
PIP
Press TV/VIDEO in the Picture-in-Picture control area
to select the input mode.
Each time you press TV/VIDEO. TV,"'VIDEO t,’"VIDE02-
and "VIDEO 3" appear In sequence.
TV/VIDEO
0
To change TV channels in the window picture
Press CH +/- in the PIP control area.
Displaying CATV input as a window picture
To use Picture-in-Picture with pay cable TV input, make the
connections to your cable converter box as shown below.
(Front of TV)
:Signal flow
(Rear of TV)
VI060 VIDEO VIDEO
Ml M2 Md
LOOP
OUT
AUnO
uc
OUT
VAR
AUDIO
OUT
©
(§)
VMC-810S/820S
(not supplied)
Signal
splitter
5 5 5
VCR
Decoder
box
CATV
cable
After making the above connections, turn the ceible
connection on by following the steps on pp. 22 - 23; then
continue with the steps below.
1 ^^ Follow steps 1 - 2 in “Changing the window
picture input mode“ on this page to select the
video input mode for your connected VCR.
I
Put your VCR on an inactive channel (channel 3 or 4).
Change pay cable TV channels with the decoder box.
To control your cable converter box with the supplied
Rentóte Commander
See p. 66.
3
St
e
8
3
Chapter 3: Using Advanced Features
