Troubleshooting 13
Display Action
Press <ENTER> to begin the signal level test, or press the
down or up arrows to select another test.
This test sends a command to the radio receiver in the
scoreboard to show its signal level on the first 2 clock digits*.
The signal level can range from ’00’ (weakest) to ‘99’
(stron
gest). The value of ‘00’ would indicate there is no server
in range. For scoreboards with 4-digit clocks, the 2 right clock
digits* will also show the missed packet count during this test
(see section below). Press any key to exit the test.
Press <ENTER> to begin the missed packet test, or press the
down or up arrows to select another test.
This test sends a command to the radio receiver in the
scoreboard to show the number of missed packets on the first 2
clock digits*. The missed packet cou nt ranges from ‘00’ to ‘99’
and indicates the number of missed packets since the start of
the test. Ideally, the number should be ‘00’ to indicate no
missing packets. A larger number indicates that there are some
signal issues, either with signal level or noise interference.
For scoreboards with 4-digit clocks, the 2 right clock digits*
will also show the signal level during this test (see previous
section). Press any key to exit the test.
X = broadcast number
Y = channel number
Press <ENTER> to begin the radio channel test, or press the
down or up arrows to select another test.
This test shows the current Broadcast Group and Channel
number settings in the console. This test also sends a
command to the radio receiver in the scoreboard to show the
receiver’s settings on the first 2 clock digits* by alternating
between “bX” and “CY”, where X is the current Broadcast
Group and Y is the current Channel. Use this menu to verify the
console and scoreboard radio settings. Press any key to exit
the test.
X = firmware major number
Y = firmware minor number
Press <ENTER> to begin the server test, or press the down or
up arrows to select another test.
This test shows the console’s radio firmware version number.
This test also sends a command to the radio receiver in the
scoreboard to show the receiver’s firmware version number on
the first 2 clock digits* by alternating between “rX” and “_Y”,
where _ is a blank digit. For example, version 1.3 would display
as “r1” followed by ”_3”. Press any key to exit the test.
RADI O TEST
-SI GNAL LEVEL
RADI O TEST
-MI SSED PACKET
RADI O TEST
-SERVER VER
SI GNAL LEVEL
ANY KEY TO EXI T
MI SSED PACKET
ANY KEY TO EXI T
RADI O TEST
-RADI O CHAN
BCAST X CHAN Y
ANY KEY TO EXI T
SERVER VER X.Y
ANY KEY TO EXI T
