Hardware Installation
Audio
Front audio
10
Mic Mic
Power
A
uD_R_Out
N.
C.
A
uD_L_Out
GND
A
uD_Vcc
K
ey
9 1
A
uD_R_R
eturn
A
uD_L_R
eturn
2
Line-out
This jack is used to connect a headphone or external speakers.
