Hardware Installation
USB Client Connector
The USB client connector supports 1 port (1 USB device controller with 1 port) and
high-speed (480Mbps) and full-speed (12Mbps) operations. It complies with USB
2.0/1.1 protocols.
1
4
USB device
detect
USB data-
Ground
3 2
USB data+
