Hardware Installation
The 1-channel I
C bus interface conforms to the version 2.1 I
C bus specification.
It operates as a master or slave device and supports a multi-master bus.
I
C Connector
4
1
3V3
I2C_DAT
Ground
2 3
I2C_CLK
