1 main components, model 100, cont – MBM Corporation DocuVac User Manual
Page 7
Advertising
T10127
November 2001
Air Feed Collator Model 100, Stacker Model 101, Model 101 HCS Operator Manual
1
2
3
4
5
6
7
8
9
1
Set up guide button
2
Third party device error message
indicator
3
Double feed / paper jam symbol
(shown by bin indicator - firm light)
4
Bin indicator
5
Misfeed / empty bin symbol
(shown by bin indicator - flashing)
6
Second / third collator error
message indicator
7
LCD display
8
Multi function buttons
9
Start / stop button
2-3
2.1 Main components, Model 100, cont.
