Selecting "Type" means to adopt a different way of drawing to display
the tracks on the chart screen, the line the following four kinds
of line : dashed / thin solid line / thick solid line / point solid line. The
"color" selecting refers to use different colors to display the track on the
chart screen, a total of 8 kinds of colors to choose.
Note The track line named as " " or "New " is the tr-
ack line being recorded for real-time track points, can not be edited,
the track lines which have been saved can only be edited after the rec-
ord is "stop".
types include
Recording Record
15
The "Dist" mode for the track record is as following: it takes length as the measure
unit for track record interval, and records 1 track point in a specified distance range.
The smallest distance interval is 0.01 nm (about 18 m).
Choosing a suitable interval value for the track record can make a full use of the
track storage space, e.g., if take 0.5 nm (about 900 m) as the record interval, for a
track record of 2100 track points, it can record at least nm miles of the routes; If
sail at the speed of 10Knots, you can record the track points for 100 hours.
Note The track recording method can be changed during the track record; The
original state before being shut down will be maintained.
Track editing
Double-click the MENU key to enter the main menu, move the cursor to the
"Track" column, and then press the right Arrow keys to move the cursor to the
" ", click ENT key, and the " " window pops up,
see Figure 22.
saving or saved track Memory
Figure 22
