TMA VXI-27 101602

C-3

C.8

INSTrument[:SELect]?

QUERY

INST:SEL?

Syntax:

Short Form :INST:SEL?

Long Form: INSTrument:SELect ?

Return value: <VAL> 1 to 31

Description: Used to determine which channel selected.

C.9

INSTrument:STATe

COMMAND

INST:STAT

Syntax:

Short Form :INST:STAT <val>

Long Form: INSTrument:STATe <val>

Description: 0 (off) sets output to 0; 1 (on) restores output voltage and current. (see Figure C-2)

FIGURE C-2. IDENTIFYING AND SELECTING DEVICES ON BITBUS

C.10 MEASure[:SCALar]:CURRent[:DC]? QUERY

MEAS:CURR?

Syntax:

Short Form: MEAS[:SCAL]:CURR[:DC]? <boolean>
Long Form: MEASure[:SCALar]:CURRent[:DC]? <boolean>
<boolean> = 0 or 1
Return Value: <num_value> (digits with decimal point and Exponent)

Description: Measures actual current. This query returns the actual value of output current (measured at the out-

put terminals) as determined by the programmed value of voltage and current and load conditions.
NOTE: The SCPI convention for this command allows the controller to establish the range and accu-
racy of the measurement if nn,nn is added after the question mark; the power supply accepts this for-
mat but sets the command warning bit (13) in the status questionable register and ignores the extra
characters. (See example, Figure C-3.)

C.11 MEASure[:VOLTage][:SCALar][:DC]?

QUERY

MEAS:VOLT?

Syntax:

Short Form: MEAS[:SCAL]:VOLT[:DC]? <boolean>
Long Form: MEASure[][:SCALar]:VOLTage[:DC]? <boolean>
<boolean> = 0 or 1
Return Value: <num_value> (digits with decimal point and Exponent)

Description: Measures actual voltage. This query returns the actual value of output voltage (measured at the out-

put terminals) as determined by the programmed value of voltage and current and load conditions.

Note: Power Supply at address 1 is an MBT 25-14, address 2 is an MST 6-12, and address 4 is a BOP 100-1.

*RST

Devices are located on the BITBUS (IEEE 1118) as noted above.

INST:SEL 1;*IDN?

Controller returns KEPCO,MBT,1,V4.2-3.0 (Channel 1 selected; device con-

nected to BITBUS channel 1 is MBT 25-14, firmware version 3.0; TMA
firmware version is 4.2).

INST:NSEL 2;*IDN?

Controller returns KEPCO,MST,2,V4.2-2.6 (Channel 2 selected; device con-

nected to BITBUS channel 2 is MST 6-12, firmware version 2.6; TMA firm-
ware version is 4.2).

VOLT? MAX

Controller returns 6.0E0 indicating a 6 volt unit (MST 6-12 at connected to

channel 2).

VOLT4? MAX;:INST:SEL?

Controller returns 1.0E2,4 indicating address 4 is selected and the device

connected to BITBUS channel 4 (BOP 100-1) is a 100 volt unit.

*IDN?

Controller returns KEPCO,BOP,1,V4.2-1.1 (Device connected to BITBUS

channel 4 is a BOP with BIT card firmware version 1.1; TMA firmware ver-
sion is 4.2).

*RST;*IDN?

Controller returns KEPCO,MBT,1,V4.2-3.0 (Channel 1 selected; device con-

nected to BITBUS channel 1 is MBT 25-14, firmware version 3.0; TMA
firmware version is 4.2).

INST:SEL 3;*IDN?

Controller returns KEPCO,PSC,3,V4.2 (Channel 3 selected; unknown

device connected to channel 3; TMA firmware version is 4.2).
