Pump Hydraulic and Electrical Diagram
(END VIEW)
(SIDE VIEW)
(TOP VIEW)
POWER FROM BATTERY
POWER FROM CONTROL
(GREEN)
WHITE WIRE FROM
TOGGLE (UP)
BLACK WIRE FROM
CONTROL (DOWN)
OUTLET PORT
Figure 24
Gravity Down Option
