7
Panel Descriptions
LAN connector, RS-232 connector
5 You can use a web browser or terminal software to
remotely control this unit.
5 You can connect a computer equipped with an RS-232
connector, and remotely control this unit.
AC IN connector
Connects the included power cord.
* Be sure to use the included power cord for connecting the power supply.
Front panel
RS-232
connector
LAN
connector
Cord hook
Clamps the power cord to secure
it in place.
[POWER] switch
Turns the power on/off.
Ground terminal
Connect this to an external earth or ground if necessary.
TALLY/GPI connector
Connect devices provided with a tally-light feature
or with control-signal output functionality to this
connector.
* For details on the specifications of the TALLY/GPI
connector, refer to p. 49.
PHONES jack (Stereo miniature type)
Connect headphones.
To AC Outlet
* The shape of the power cord’s plug
varies depending on the country.
