6.1 Interface assignment
6 Interfaces
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
6-2
6.1.1 Connection to SafetyBUS p
Connection to SafetyBUS p 6- ][BA_Verdrahtung SB p
Please refer to the SafetyBUS p Installation Manual.
6.1.2 Connection to INTERBUS
Connection to INTERBUS 6- ][BA_Verdrahtung IBSe
The connection to INTERBUS is made via a male 9-pin D-SUB connec-
tor "IBS-IN" and a female 9-pin D-SUB connector "IBS-OUT". Please re-
fer to the guidelines issued by the INTERBUS Club.
The INTERBUS specification stipulates equipotential bonding between
the INTERBUS subscribers. Connect the screen from the incoming in-
terface on the PSS ('IBS-IN') to the screen on the outgoing interface of
the INTERBUS subscriber immediately before it in the bus topology.
This equipotential bonding cable must have a cross section of at least
10 mm
2
. The equipotential bonding cable can also be connected to the
functional earth of the PSSu, e.g. via the C-rail.
6.1.3 Connection via USB
Connection via USB 6- ][BA_Verdrahtung USB
Please note the requirements of the USB standard for USB 2.0 and for
Mini-B USB ports.
The maximum cable runs for USB connection cable are 5 m.
