8.1 Technical details
8 Technical details
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
8-2
SI-Kennzahlen_PSSu_Kopf
Si_Kennzahlen_Erläuterung
All the units used within a safety function must be considered when cal-
culating the safety characteristic data.
Technische Daten_Satz Normen
Vibration to EN 60068-2-6
Frequency
10 - 150 Hz
Max. acceleration 1g
Shock stress
EN 60068-2-27
15g
11 ms
EN 60068-2-29 10g
16 ms
Protection type
Mounting (e.g. cabinet)
IP54
Housing IP20
Airgap creepage in accordance with EN 60664-1
Overvoltage category
II
Pollution degree 2
Mechanical data
Housing material
Front
PC
Bottom PC
Dimensions
Height
128.4 mm
Width 75.2 mm
Depth 79.4 mm
Weight 170 g
Safety characteristic data
Unit Operating mode
EN ISO 13849-1
PL EN 954-1
Category EN IEC 62061
SIL CL
PFH [1/h] t
M
[year]
Logic --- PL e (Cat. 4) Cat. 4 SIL CL 3 2.88E-09 20
Environmental data
