FORM NO. L-21204-C-0908 24
SPECIFICATIONS
PART NUMBERS
RSTC1000 (Modbus RTU Network) 964523
RSTC1100 (Profi bus DPV1 Network) 964528
POWER
Input
24 VDC at 600 mA
TEMPERATURE
Operating Temperature
0-60 C [32˚ - 140˚ F]
DIGITAL SIGNALS
Alarm Outputs
5-24 VDC, 140 mA max, current sinking
Control Inputs 12-24 VDC, 20 mA max
ANALOG SIGNALS
Diameter Sensor Input
0-12 VDC
Remote Tension Setpoint Input 0-12 VDC
Load Cell Inputs 2 channels, 0-1 VDC
Control Output 1 0-10 VDC and 4-20 mA
Control Output 2 0-10 VDC and 4-20 mA
SENSOR EXCITATIONS
Load Cell Excitation
6 VDC
Other Sensor Excitations 24 VDC @ 100 mA max & 12 VDC @ 60 mA
CERTIFICATIONS
Certification
CE
