Test Setup
Learning Setup
¾ Learning Mode: Scroll down to
choose Learning Mode as Never,
Once or Every Trial.
¾ Delay Time After Learning: Set the
time gap between Learning and the
next step.
¾ Frame Count: The number of frame
to be sent.
¾ Frame Gap: The gap in bits between
frames.
Click OK to save the settings, click
Cancel to exit this setting window without
saving, or click Default to recover the
setting to the default value.
Frame size with CRC (Bytes)
Starting from Set the starting frame size with CRC on this field.
Stopping at Set the last frame size with CRC on this field.
Frame Size Step Set the frame size to be added on each step with CRC on this field.
Custom
Selecting the Custom function will enable the Edit
button. Click the Edit button to pop up the Custom
Frame Size window.
¾ Frame Sizes: Shows the default frame size to
select.
¾ Sort: sort the order of the current frame sizes list
as ascending or descending.
¾ Move: You can change the order of each frame
from the frame sizes list here.
¾ Add/Remove: Add a new frame size to the frame
sizes list in the range of 60-2036, or select a
frame from the frame size list and remove it by
clicking the Remove button.
Click OK to save the settings, click Cancel to exit this
setting window without saving, or click Default to
recover the setting to the default value.
