2.6.1 -HV Option Specifications
The -HV option provides an AC only output range of 0 to 400 Vac L-N. Specifications unique to
the -HV option are shown in the table below.
Output Parameter MX15 MX30/2 MX45/3
Modes
Pi Controller AC
Voltage:
Ranges (L-N): 0 -400 V
Resolution: 0.1 V
Accuracy: ± 0.4 V
Output Coupling AC coupled
Power (total power for all phases, either range, at full scale voltage)
AC Mode 15 KVA 30 KVA 45 KVA
Current
Note: Current, maximum amps per phase available between 50 and 100 % of voltage range.
MX15-1
37.5 A MX15-1
75 A MX15-1
112.5 A
Peak Current
AC Mode MX15-1
112.5 A MX15-1
225 A MX15-1
337.5 A
