SECTION 2
CALIBRATION PROCEDURE
2.1 CALIBRATION SETUP
Prior to starting the calibration procedure, gather the necessary equipment
(Section 2.1.1), then power up the chassis and allow it to warm up for 15
minutes.
2.1.1 E
QUIPMENT
R
EQUIRED
Voltage/Current Source/Calibrator: Krohn-Hite EDC 521.
Current Shunt: Prodigit 7550.
Digital Multi-meter (DMM): Agilent 34401A.
DC Power Supply: SGA80-125. (Supply may depend upon models
being calibrated. This model covers any module in the SLD
family.)
Current Probe: Tektronix A6303.
2.2 CHANNEL A CALIBRATION
Press CHAN key to light the A LED.
Press both MODE and LIMIT keys simultaneously to enter calibration mode.
Initial default mode is Constant Current (CC) Mode.
SLD Calibration Manual 2-1
