Chapter 2 Hardware Installation
Chapter 2
OFF
1 On: Single LVDS
1 Off: Dual LVDS
2 On: VESA (24bpp)
OFF
2 Off: JEIDA or VESA
(18bpp)
The Switch 1 is used to select the LVDS channel and the color of bits per pixel on the system.
LVDS Channel and bpp Select
SW1
