56 DR ® COMMERCIAL LEAF and LAWN VACUUM
Parts List - Blower/Chipper Assembly, Subaru Engine
NOTE: Part numbers listed are available through Country Home Products.
Ref# Part# Description
01 214721 Mount, Engine
02 112431 Washer, Lock, Split, 5/16"
03 233701 Knob, Engine Mount, 5/16"
04 214711 Engine, 9.0HP Subaru E/S, EX27D
05 231031 Bolt, Carriage, 3/8"-16 x 1-3/4", GR5, ZP
06 229131 Bolt, Carriage, 3/8"-16 x 2", GR5, ZP
07 112391 Washer, Flat, 3/8", USS
08 110751 Nut, Nylon Lock, 3/8"-16
09 214891 Tensioner, Belt
10 229121 Bolt, 3/8"-16 x 4-1/2", HCS, GR5, ZP
11 214851 Pulley, Engine
12 191301 Washer, Flat
13 229111 Bolt, HCS, 7/16"-20 x 1, GR8, ZP
14 164521 Key, Square, 1/4" x 2"L
15 230951 Clamp, Cable Insulated
16 112431 Washer, Lock, Split, 5/16"
17 229141 Screw, 5/16"-24 x 5/8", SHC, GR5, ZP
18 150141 Cable, Ground, 16"
19 214811 Harness, Safety Switch
20 223281 Guard, Side, Belt
21 146811 Clip, Mtg, (Alum Frame)
22 101811 Washer, Lock, Split, 1/4"
23 114701 Bolt, SHC, 1/4"-20 x 1/2"
24 214831 Guard, Top Cover Belt
25 112381 Washer, Flat, 1/4"
26 157301 Bolt, 1/4"-20 x 3/4"
27 214881 Belt, V
28 214861 Pulley, Impeller Drive
29 165141 Washer, Flat
30 180811 Washer, Lock, Split, 3/8"
31 165131 Bolt, 3/8"-24 x 1-1/4"
32 142321 Key, Square, 1/4" x 1"L
33 214751 Bearing, Flanged
34 229091 Bolt, HCS, 1/2"-13 x 1-1/2", GR5, ZP
35 112421 Washer, Lock, Split, 1/2"
36 229101 Nut, Hex, 1/2"-13, GR5, ZP
37 189021 Caster, 2"
39 110731 Nut, Nylon, Lock, 1/4"-20
40 214701 Bracket, Cover Positioning
Ref# Part# Description
41 104831 Battery, 12V, 17AH
42 124511 Clamp, Battery, 7-1/8"W x 5-1/2"H
43 111481 Bolt, HCS, 1/4"-20 x 1-3/4"
44 112481 Washer, Lock, 1/4" External Tooth
45 214801 Standoff, Housing/Mount
46 231051 Bolt, HSC, 5/16"-18 x 5", GR5, ZP
47 112411 Washer, Flat, 5/16" USS
48 110761 Nut, Nylon Lock, 5/16"-18
49 187321 Housing, Chipper, Back
50 186901 Housing, Inlet, Chipper, Front
51 123211 Bolt, 5/16"-18 X 3/4", HCS
52 187341 Chipper Hopper
53 193361 Bolt, HSC, 5/16"-18 x 1", GR5, ZP
54 187551 Nut, Nylon Lock, 5/16"-18
56 225731 Bracket, Switch
57 214741 Shaft, Impeller Drive
58 214761 Ring, Retainer
59 214731 Impeller, W/Knife
63 188331 6.00 Adapter, Tube, Steel
64 221141 Nut, Wing, 5/16"-18
65 112381 Washer, Flat, 1/4" USS
66 110961 Pin, Spring 3/16 x 1
Not Illustrated
231041
Jack, Trailer
188711 Lanyard
202581 Chipper Knife Kit
233711 Label, Belt Safety
231201 Label, Operating Instructions
129601 Bolt, 3/8"-16 x 3", HCS
112391 Washer, Flat, 3/8", USS
110751 Nut, Nylon Lock, 3/8"-16
