Output Layout for Default AMI Centra Page Configuration
Outputs in ACT
Configuration
Where Input terminal is Located:
Description
1
Output 1 on AMI TB1: 2 & 1
Not used
2
Output 2 on AMI TB1: 3 & 1
Not used
3
Output 3 on AMI TB1: 4 & 1
Not used
4
Output 4 on AMI TB1: 5 & 1
Not used
5
Output 5 on AMI TB1: 6 & 10
Not used
6
Output 6 on AMI TB1: 7 & 10
Not used
7
Output 7 on AMI TB1: 8 & 10
Not used
8
Output 8 on AMI TB1: 9 & 10
Not used
9
Output 1 on I/O controller TB10:1
Not used
10
Output 2 on I/O controller TB10:2
Not used
11
Output 3 on I/O controller TB10:3
Not used
12
Output 4 on I/O controller TB10:4
Not used
13
Output 5 on I/O controller TB10:5
Not used
14
Output 6 on I/O controller TB10:6
Not used
15
Output 7 on I/O controller TB10:7
Not used
16
Output 8 on I/O controller TB10:8
Not used
17
Output 9 on I/O controller TB10:9
Not used
18
Output 10 on I/O controller TB10:10
Not used
19
Output 11 on I/O controller TB10:11
Not used
20
Output 12 on I/O controller TB10:12
Not used
21
Output 13 on I/O controller TB10:13
Not used
22
Output 14 on I/O controller TB10:14
Not used
23
Output 15 on I/O controller TB10:15
Not used
24
Output 16 on I/O controller TB10:16
Not used
25
Output 17 on I/O controller TB9:1
Not used
26
Output 18 on I/O controller TB9:2
Priority 1 Crew’s
Quarters active
27
Output 19 on I/O controller TB9:3
Priority 2 Crew’s
Quarters active
28
Output 20 on I/O controller TB9:4
Priority 3 Crew’s
Quarters active
29
Output 21 on I/O controller TB9:5
Telephone Page
