Specifications
Power Supply Requirements
Connection to a 12 to24 V dc (UL listed) class 2 power source ....................................... 3.2 A maximum*
Power consumed @ 12 V dc.................................................................................... 38.4 watts maximum*
Power consumed @ 24 V dc...................................................................................... 76.8 watts maximum
Auxiliary outputs.................................................... Sink 100 mA maximum, per output to circuit common
and pulled up to the power input voltage
*Calculations are only accurate if a single power supply is used to power the I/O PCBA and associated
output control lines. The current draw is based on all outputs being active simultaneously and sinking
100 mA each.
Mechanical
Enclosure .................................................................Steel body and cover; black fine-textured paint finish
Mounting .............................................................................................................................. Wall or shelf
Dimensions ..........................................................7.50 W
× 5.625 D × 1.20 H inches (191 × 143 × 31 mm)
Weight ............................................................................................................................. 2 lbs. (0.902 kg)
Environmental
Temperature range................................................................................ +32º F to +122º F (0º C to +50º C)
Replacement Parts
Part Number Description
69434-001 PCBA, I/O Controller
