GAI-Tronics XCP0100A 4-Channel Expansion Kit - Manual (Page 2)

Pub. 43003-021E
Model XCP0100A 4-Channel Expansion Kit Page 2 of 7
f:\radio products-current release\43003\43003-021e\43003-021e.doc
03/12
Pre-Installation Notice
Before installing the CP-CSD Slave PCBA, the master firmware version of the ICP9000 Desktop or
Navigator Series Console must be determined. To determine the master firmware version, momentarily
depress the RESET button located on the rear panel of the unit. The master firmware version will appear
in the console display window (for approximately 5 seconds) as MAST, followed by a version number
and letter (example: MAST4D). If the version number/letter is “4x” or higher (“x” being an alphabetic
letter), no changes are required to the CP-CSD board and installation can continue.
If the version number/letter is “3x” or lower, the slave firmware must be changed due to incompatibility
with the master firmware and CARD Suite software (found on the XAC4000A Programming Bundle
CD). Observing precautions for handling electrostatically sensitive devices, remove EPROM No. 50086-
085 from socket U502. Install EPROM CPSLAV2J in its place. Installation can now continue.
N OTE : If you are interested in upgrading your console to the latest feature firmware, upgrade kits are
available. Please contact our Customer Service department at 1-800-492-1212 for price and availability.
Installation
If installing this kit in the Motorola CommandPLUS, use the supplied hardware in the envelope
labeled “Motorola Brand Hardware.” See the “Motorola CommandPLUS Hardware Installation”
instructions on page 5 for this hardware only. For the remainder of the installation, follow the
instructions provided for the ICP 9000 Series Desktop Console. Motorola is a registered trademark
of Motorola Incorporated.
ICP9000 Series Desktop Console
1. Disconnect the power from the ICP9000 Series Desktop Console and remove all attached cables from
the rear cover.
2. Remove the four screws securing the rear panel. Gently pull the rear cover from the housing and
disconnect the ribbon cables (SLV-CBL-P) attached to the surge suppression PCBA. Lay the rear
panel flat. See Figure 1.
3. Mount the new CLP PCBA next to the existing CLP board using the four threaded stand-offs with the
#4-40 screws provided. See Figure 2.
4. Remove the earth ground terminal screw from the bottom right corner of the existing CLP PCBA.
Attach the supplied surge protection cable to the earth ground screw, and the other end to the
matching location on the new CLP PCBA.
5. Attach the SLV-CBL-P ribbon cable to its matching connectors between the CLP PCBA at J25 and
the CSD PCBA at P25. Also reattach the original ribbon cable.
