4 471833 • Model FPB, Rev. 1, August 2008 Copyright 2008 © Greenheck Fan Corporation
Greenheck Catalog FPB provides additional information
describing the equipment, fan performance, available
accessories, and specification data.
®
Phone: (715) 359-6171 • Fax: (715) 355-2399 • E-mail: [email protected] • Web site: www.greenheck.com
Warranty
Greenheck warrants this equipment to be free from defects in material and workmanship for a period of one year from
the shipment date. Any units or parts which prove defective during the warranty period will be replaced at our option
when returned to our factory, transportation prepaid. Motors are warranted by the motor manufacturer for a period of
one year. Should motors furnished by Greenheck prove defective during this period, they should be returned to the
nearest authorized motor service station. Greenheck will not be responsible for any removal or installation costs.
As a result of our commitment to continuous improvement, Greenheck reserves the right to change specifications
without notice.
AMCA Publication 410-96, Safety Practices for Users and
Installers of Industrial and Commercial Fans, provides
additional safety information. This publication can be
obtained from AMCA International, Inc. at: www.amca.org.
Parts List
Always provide the unit model and serial number when requesting information.
1. Scroll housing
2. Motor
3. Drive frame
4. Wheel
5. Inlet collar (1 1 ⁄
2
inch collar extruding out of the scroll)
3
2
5
4
1
2
3
4
Isometric Back View Isometric View Inlet View
