Figure 3: Label applied to
dampers with factory
mounted duct smoke
detectors.
Copyright © 2010 Greenheck Fan Corporation
463813 Smoke Detector IOM Rev 7 Aug 2010
Smoke detector r equir es 100 fpm minimum
air velocity in duct. For damper activation
r equir ements when system velocity is less
than 100 fpm, the local authority having
jurisdiction should be consulted.
Refer to smoke detector installation
instructions and Gr eenheck IOM - Smoke
Detector Supplement FS for dampers with
factory mounted duct smoke detectors.
458565
TOR w/ EP switch
DUCt SMokE DEtECtoR
WIRINg DIAgRAMS
