1-2 HD3070 with Manual Gas Console Product Configuration Manual
4
SPECIFICATIONS
System Requirements
Gas Requirements:
Plasma Gas Types ......................................Oxygen (O
2
), Air
Shield Gas Type ..........................................Oxygen (O
2
) and Nitrogen (N
2
) mixture,
Methane, Air, Methane/Air mixture
Oxygen Gas Quality ....................................99.95% pure (liquid gas recommended)
Nitrogen Gas Quality ...................................99.995% pure (liquid gas recommended)
Air Quality ....................................................Clean, dry, oil-free
Methane Quality ..........................................93% pure (commercial grade)
All Gas Inlet Pressures ...............................120 psi (8.3 bar)
Oxygen Flow rate ........................................77.8 scfh (2203 l/hr) at full scale
Nitrogen Flow rate .......................................83.1 scfh (2353 l/hr) at full scale
Air Flow rate ................................................81.7 scfh (2313 l/hr) at full scale
Methane Flow rate.......................................110 scfh (3114 l/hr) at full scale
Torch Coolant Requirements
(Torch coolant requirements are provided by power supply.)
Coolant Tank Capacity.................................2.9 gallons (11 liters)
Coolant ........................................................Deionized water or mixture (propylene glycol and
deionized water)
Flow Rate ....................................................1 gpm (3.8 l/m)
Pressure ......................................................150 psi (10.3 bar)
HD3070 Power Supply, Manual
Dimensions and Weight
Width ...........................................................24-1/4" (616 mm)
Height ..........................................................36" (914 mm)
Depth ...........................................................38-1/4" (972 mm)
Weight .........................................................545 pounds (247 kg)
HD3070 Manual Gas Console
Input Power from Power Supply (intrlk'd) ....120 VAC
Output Power to Off-Valve Assy ..................120 VAC
Outputs to CNC ...........................................Active (low or closed)
Dimensions and Weight
Width ...........................................................12-1/2" (318 mm) w/o hardware;
15" (381 mm) w/hardware
Height ..........................................................15" (381 mm)
Depth ...........................................................10" (254 mm) w/o hardware
11-1/2" (292 mm) w/hardware
Weight .........................................................35 pounds (16 kg)
