94
8 Maintenance and care
Remove any grime and dust with a soft, dry or silicon-treated
cloth. Never use detergents that could damage plastic parts.
Forming the flash capacitor
The flash capacitor incorporated in the flash unit undergoes
a physical change when the flash unit is not switched on for
prolonged periods of time. For this reason it is necessary to
switch on the mecablitz for approx. 10 minutes every 3
months. The batteries must supply sufficient power for flash
readiness to be indicated within 1 minute after the mecablitz
was switched on.
Metz does not accept any liability for faulty functions
or damage to the mecablitz caused by the use of
accessories from other manufacturers! ☞
9 Technical data
The flash unit can be updated by the METZ customer
service department.
Zoom reflector positions: 28 mm - 35 mm - 50 mm - 85 mm
Tilting range and locking positions of flash head:
vertically 30° - 45° - 60° - 90°
Flash duration: 1/500 s - 1/30,000 s
Colour temperature: approx. 5500 K
Film speed: ISO 25 to ISO 800
Synchronisation: Low-voltage ignition
Number of flashes (at full light output):
approx. 160 with NiCad batteries (600 mAh)
approx. 450 with high-capacity alkaline manganese batteries
approx. 320 with NiMH batteries (1600 mAh)
