16
Video Server Cable Definition and Requirements
The Network Video Server requires a network cable to carry the video signals to the
remote viewing site.
Network Cable
Network cable max length is 328 feet (100m). To avoid signal attenuation, OpenEye
recommends that you do not exceed 295 feet (90m). You can use Power over Ethernet
(PoE) to power compatible cameras using network cables up to the max length.
Power Connection
Make sure the power cable is correctly and firmly connected to the video server.
Power Wire Length Specifications
Wire
Gauge Maximum
Distance Wire
Gauge Maximum
Distance
22 27 feet 14 175 feet
20 44 feet 12 279 feet
18 69 feet 10 444 feet
16 110 feet
Note
Ensure that the power supply corresponds with the power requirements of the
video server or the device may be damaged. Contact a qualified maintenance
engineer with any problems.
Ethernet Cable Connection
Connect one end of the CAT 5 Ethernet cable to the RJ-45 connector of the camera and
the other end of the cable to the network switch or router.
Note
In some cases, you may need to use an Ethernet crossover cable when
connecting the video server directly to the recorder.
Check the status of the link indicator and activity indicator LEDs. If the LEDs are unlit,
check the LAN connection.
The Green link light indicates a good network connection.
