10
TASCAM US-600
8 LEVEL knob
Use to adjust the input levels of LINE
OUT 1/2 and PHONES jacks.
CAUTION
Turn the LEVEL knob to the minimum
volume before connecting headphones.
Failure to do so could cause sudden loud
noises and damage hearing, for example.
9 MON MIX knob
Use this knob to adjust the mix of signals
output through the LINE OUT 1/2 jacks
and the PHONES jack. Use this knob to
adjust the balance between the signals
input through the unit’s connectors (MIC
IN and LINE IN) and the signal output
from the computer by USB. Turn it all the
way to the left (INPUT) to output and
monitor only the signals input through
the unit, and turn it all the way to the
right (COMPUTER) to output and monitor
only the signals sent from the computer
by USB.
0
Gain knob
Use these to individually adjust the input
levels of MIC/INST IN 1, MIC/LINE IN 2
and MIC/LINE IN 3/4 connectors. Turn
them all the way to the left to minimize
the level and all the way to the right to
maximize it.
2 − Names and Functions of Parts
