6
TASCAM US-600
1 – Introduction
Thank you for your purchase of the TASCAM
US-600 USB 2.0 Audio/MIDI Interface.
Before connecting and using the unit, please
take time to read this manual thoroughly
to ensure you understand how to properly
set up and connect the unit, as well as the
operation of its many useful and convenient
functions. After you have finished reading
this manual, please keep it in a safe place for
future reference.
You can also download the Owner’s Manual
from the TASCAM web site (http://tascam.
com/).
Please also check the above site for the latest
manual updates.
If any data is lost from another MIDI device,
hard disk, MO disc or other media in the same
system where this unit is used, TASCAM will
bear no responsibility for its recovery, nor will
it provide any compensation for such loss.
Main features
USB 2.0 audio/MIDI interface •
24-bit/96 kHz audio interface. •
Coaxial Digital inputs and outputs (can be
•
set to either S/PDIF or AES/EBU)
Signals can be input from 4 analog and 2
•
digital channels at the same time
Four XLR mic inputs (balanced) with high
•
performance microphone preamps
Four standard input jacks (combo jacks
•
with XLR). Channel 1 allows unbalanced
input of high impedance electric guitars
and basses that are directly connected;
channels 2-4 are balanced inputs
1 unbalanced stereo line outputs (RCA
•
jacks) and a headphone output.
Output level from the unbalanced stereo
•
line output and headphones jacks can be
adjusted using a volume knob (same knob
controls both simultaneously)
MIDI IN/OUT.
•
Direct Monitor function allows zero-latency •
monitoring of the input.
Inputs 1 and 2, and 3 and 4 can be set to be
•
monitored as either a stereo pair or as two
mono channels
Input and overload LED indicators included
•
for each input channel
MON MIX knob allows the balance between
•
the input signals and the output from the
computer to be adjusted for monitoring
Powered by the included TASCAM PS-P520
•
AC adaptor
Dedicated drivers for both Windows
•
(Windows XP, Windows Vista, Windows 7)
and Mac (OS 10.5, OS 10.6)
USB 2.0 High Speed (480 MHz) compatible
•
(does not function with USB 1.1)
Can supply 48 V phantom power to 4 mic
•
inputs
Cubase LE 5 software included
•
A note about computer operation
If you are unsure about how to perform
basic computer operations appearing in this
manual, please refer to the owner’s manual
that came with your computer.
To use this unit, you must use the included
CD-ROM to install the dedicated driver on
your computer. For details about installation,
see “Installing the driver and control panel”
on page 13 in “3 – Installation”.
