NVR 2.3 (V2.3.05.11) User’s Manual
name and the description will be shown in the event manager.
9.
Threshold (%): Enter the threshed level of this motion detection region. Lower threshold
levels, which mean that smaller portion of the motion region would be considered as
motions, are more easily triggered, but may give more false alarms. It may range from
1-100.
10. Motion Region: Click and Drag to setup the location and size of the target motion region
in view window.
After you
’ve completed setup, please click “Apply” to save into to camera and NVR. This
process may take a short while. If you have pressed
“Get motion setting” and leave the page
without applying, the system will provide a warning message to urge you to save all changes.
If you have changed the motion detection settings via the web configurator, please remember
to come back to NVR and press Get device settings, then click apply to save to NVR. This is to
ensure that the settings in NVR are always in sync with the device.
NOTE:
For ACTi TCM/TCD model devices, motion detection is available when codec is
either H.264 or MPEG4. MJPEG does not support motion detection.
