NVR 2.3 (V2.3.05.11) User’s Manual
4. Trigger DO2: Click to enable / disable DO2 when this event occurs. You may also setup
the duration for DO2 to be triggered.
5. Beep: Click to setup NVR to beep upon event. User can also select how many times does
it beep and the duration of each beep.
6. Play Audio File: Click to setup NVR to play your desired audio file for a number of
repetitions. User can enter the path of the audio file to be played. Please note that you may
either beep or play audio file, but cannot do both at the same time.
NOTE:
Play Audio File function only works on NVR Workstation, not on Web Client.
7.
Don’t beep: Click to disable beep function of NVR.
8. Activate Hot-Spot Window: Click to display video from the camera on Hot-Spot window
upon event. (The upper left main preview window). You may also select the duration for the
video to display on the Hot-spot window.
9. Activate Pop-Up Window: Click to display video form the camera on the event pop-up
window upon trigger. You may also select the duration for video to be displayed in the Pop
up window. Please note that you may activate either the Hot Spot window or the Pop-up
window, but not both at the same time.
10. None: Click here to disable both Pop-up and Hot-Spot windows.
11. Enable PTZ Command: Upon event, NVR can move specific camera to specific PTZ
presets. Check this box to enable this function.
12. Camera Channel and Preset number: Select which camera to move and which PTZ
preset to go to. Please note that you need to configure PTZ presets for that camera first.
13. Upload Snapshot File to FTP Site: Click to enable NVR to upload FTP to a FTP site
upon this event. You need to configure FTP settings in System Setup → System for this to
function correctly. Please also make sure the FTP server setting is correct and the folder
access rights are properly configured.
14. Enable Execute Command and enter its File Path: Click to enable NVR to execute a
certain command upon this event. This is a very power function. User can use it to
integrate NVR’s event handling with other programs. User can enter the path of the
command to be executed upon event.
