4.9 Alarm
ALARM SETUP
NO PRI FUN
IN
OUT HLD LATCH
0
00 NC
OFF
03
OFF
0
A0 NO
OUT
03
OFF
03
– – – OFF
OUT
03
OFF
04
– – – OFF
OUT4
03
OFF
05
– – – OFF
OFF
03
OFF
06
– – – OFF
OUT
03
OFF
07
– – – OFF
OUT
03
OFF
08
– – – OFF
OUT4
03
OFF
DWELL:
03
RELAY OUT SETUP
SAVE AND EXIT (ESC TO CANCEL)
NO:
Alarm input number
PRI (priority): The lower number has higher priority. (0-8)
FUN (function): Stored function number to be called by alarm.
IN:
NO/NC - normally open/closed; OFF - ignore
OUT:
OUT~OUT4 - Relay out ,,3,4, OFF - No output.
HLD (HOLD):
Alarm will be held for programmed time (03 to 99 seconds)
LATCH:
ON - Shows all alarms including past alarm.
OFF - Shows activated alarms only.
DWELL:
means the dwell time during multiple alarms, 03 to 99 seconds.
The RELAY OUT setup is helpful when the outdoor housing is used with the dome.
Example: When you connect the relay output of the dome to the heater connector of the outdoor housing, the relay output can operate during the setting
time only.
RELAY OUT SETUP
OUT:
ALARM
OUT:
MIN
OUT3:
ALARM
OUT4:
5 MIN
EXIT (ESC TO EXIT)
ALARM: The relay output is operated during an alarm operation or by the short key of our keyboard.
1-5 MIN (minute): The relay output is operated during this setting time only by the function run of the dome menu or the short key of our keyboard.
NOTE: This 1-5 MIN setting is not operated by an alarm.
NOTE: If you disable Alarm by dip switch, Alarm menu will be displayed following screen.
ALARM SETUP
ALARM DISABLED
CHECK THE DIP SWITCH
EXIT (ESC TO EXIT)
There are 9 levels of priority. The function can be selected by Preset, Auto scan, Pattern or Tour and „0” is the highest priority. Lower priority alarms won’t be
serviced until the higher priority alarm is completed. Equal priority alarms will be serviced repeatedly with the dwell time.
