5. Click Reset to clear the query criteria and display all CE devices.
Importing CE devices
Perform this task to import CE devices to MPLS VPN Management. Before importing the devices, make
sure the devices to be imported meet the following conditions:
• Enables with SNMP and are enabled with SNMP.
• Added into IMC, and recognized and managed by IMC.
• Not imported as P or PE devices.
To import CE devices:
1. Click the Service tab.
2. From the navigation tree, select MPLS VPN Manager > VPN Devices > CE Device List.
The CE Device List page displays all CE devices.
3. Click Import on top of the CE Device List area.
The Import Device page appears.
4. Select the CE type from the box next to Please select CE type to be imported. Options are CE, VMCE,
and MCE.
5. Click Select to select the CE devices to be imported.
There are two methods for selecting devices, By View or using the Advanced option. See "
Adding
Devices by View " and " Adding Devices by Advanced Query ."
6. Highlight the devices you want to select and do one of the followings:
{
To add them to the Selected Devices list, click Add selected .
{
To select all of the devices displayed in the Devices Found list, click Add all .
{
To remove one or more, select them and click Remove selected .
{
To remove all of the selected devices, click Remove all .
7. Confirm that the found devices have been added.
8. Click OK to enter the Import Device page. The selected devices now appear in the page.
9. Check the imported devices:
{
To add more devices, repeat step 5.
{
To delete devices, select one or multiple devices in the list, and click Remove.
10. Click OK.
The page for import progress appears. You can view the import process and result.
Adding/Modifying a non-managed CE
Some CE devices cannot be managed by IMC. Perform this task to create a virtual CE to represent a
non-managed CE in the MPLS VPN topology to keep the topology complete.
To add/modify a non-managed CE:
1. Click the Service tab.
