GUIDE TO INSTALLATION AND OPERATION
96 | LGK-3901/DSK-3901
ANNEX 1 – Front Panel Menu
The structure of the LGK-3901 and DSK-3901 front panel menus for v3.1 software is shown in the following table.
Front Panel Menu Name LGK DSK Description
STATUS › ›
GENERAL STATUS › › General system status
BACKPLANE › › “LGK-3901-3DRP-R”, “DSK-3901-3DRP-R” or “No Rear”
TEMPERATURE › › Temperature of the FPGA
FPGA 1.0V › › Voltage of the 1.0V supply rail
FPGA 2.5V › › Voltage of the 2.5V supply rail
FPGA 3.3V › › Voltage of the 3.3V supply rail
TIMECODE STATUS › ›
“LTC” or “VITC” if valid TC is present; otherwise “BAD-Internl”
“DF” for dropframe; “ND” for no dropframe
“Fwd” or “Bwd” shows LTC direction
TIMECODE TIME › › “Ext” if valid external time code; “Int” if using internal clock
REF STATUS › ›
REF SOURCE › ›
[4.4] “URS” if locked to REF-1801 card; “External Ref” if locked to EXT
REF; “SDI PGM In” if locked to PGM IN; “Free Running” otherwise.
URS MODE › ›
“URS 25”, “URS 29.97”, “Free Running” , “URS No Ext Ref”, or “Not
Present”
EXT REFERENCE › ›
EXT REF STATUS › › “Locked” if the external reference is valid; “Unlocked” if missing
EXT STANDARD › ›
“625 Line”, “525 Line”, “1080i/59.94”, “1080i/50”, “720p/59.94”, “720p/50”,
“1080p/59.94 A”, “1080p/50 A”, “1080p/59.94 B”, “1080p/50 B” or
“Unknown” if not present
INPUT STATUS › ›
PGM INPUT › ›
VIDEO STANDARD › ›
“625 Line”, “525 Line”, “1080i/59.94”, “1080i/50”, “720p/59.94”, “720p/50”,
“1080p/59.94 A”, “1080p/50 A”, “1080p/59.94 B”, “1080p/50 B” or
“Unlocked” if signal is not present
INPUT TIMING › ›
Input timing relative to the Program Output in lines/samples; “Input
Unlocked” if video signal is not present
FILL-1 INPUT › ›
VIDEO STANDARD › › See “PGM Input” (above)
INPUT TIMING › › See “PGM Input” (above)
KEY-1 INPUT › ›
VIDEO STANDARD › › See “PGM Input” (above)
INPUT TIMING › › See “PGM Input” (above)
FILL-2 INPUT › ›
VIDEO STANDARD › › See “PGM Input” (above)
INPUT TIMING › › See “PGM Input” (above)
KEY-2 INPUT › ›
VIDEO STANDARD › › See “PGM Input” (above)
INPUT TIMING › › See “PGM Input” (above)
AUDIO FEED 1 › ›
CHANNEL 1 › › “PCM”, “Non-PCM” or “Unlocked”
CHANNEL 2 › › “PCM”, “Non-PCM” or “Unlocked”
CHANNEL 3 › › “PCM”, “Non-PCM” or “Unlocked”
CHANNEL 4 › › “PCM”, “Non-PCM” or “Unlocked”
CHANNEL 5 › › “PCM”, “Non-PCM” or “Unlocked”
CHANNEL 6 › › “PCM”, “Non-PCM” or “Unlocked”
CHANNEL 7 › › “PCM”, “Non-PCM” or “Unlocked”
CHANNEL 8 › › “PCM”, “Non-PCM” or “Unlocked”
