GUIDE TO INSTALLATION AND OPERATION
LGK-3901/DSK-3901 | 121
ANNEX 2 – GPI Output Event List
GPI Output Event
LGK
DSK
Description
> NONE <
No event is selected
EXT REF UNLOCKED
External reference is unlocked
EXT REF LOCKED
External reference is unlocked
EXT REF MISMATCH
External reference mismatch with output video standard
EXT REF MATCH
External reference matches output video standard
PGM IN VIDEO LOSS
PGM IN video loss
PGM IN VIDEO PRESENT
PGM IN video present
PGM IN VIDEO MISMATCH
PGM IN video mismatch with output video standard
PGM IN VIDEO MATCH
PGM IN video matches output video standard
PGM IN VIDEO TIMING OUT OF RANGE
PGM IN timing is out of range (<-1 line with respect to PGM OUT)
PGM IN VIDEO TIMING IN RANGE
PGM IN timing is within range
FILL 1 VIDEO LOSS
FILL 1 video loss
FILL 1 VIDEO PRESENT
FILL 1 video present
FILL 1 VIDEO MISMATCH
FILL 1 video mismatch with output video standard
FILL 1 VIDEO MATCH
FILL 1 video matches output video standard
FILL 1 VIDEO TIMING OUT OF RANGE
FILL 1 timing is out of range (<-1 line with respect to PGM OUT)
FILL 1 VIDEO TIMING IN RANGE
FILL 1 timing is within range
KEY 1 VIDEO LOSS
KEY 1 video loss
KEY 1 VIDEO PRESENT
KEY 1 video present
KEY 1 VIDEO MISMATCH
KEY 1 video mismatch with output video standard
KEY 1 VIDEO MATCH
KEY 1 video matches output video standard
KEY 1 VIDEO TIMING OUT OF RANGE
KEY 1 timing is out of range (<-1 line with respect to PGM OUT)
KEY 1 VIDEO TIMING IN RANGE
KEY 1 timing is within range
FILL 2 VIDEO LOSS
FILL 2 video loss
FILL 2 VIDEO PRESENT
FILL 2 video present
FILL 2 VIDEO MISMATCH
FILL 2 video mismatch with output video standard
FILL 2 VIDEO MATCH
FILL 2 video matches output video standard
FILL 2 VIDEO TIMING OUT OF RANGE
FILL 2 timing is out of range (<-1 line with respect to PGM OUT)
FILL 2 VIDEO TIMING IN RANGE
FILL 2 timing is within range
KEY 2 VIDEO LOSS
KEY 2 video loss
KEY 2 VIDEO PRESENT
KEY 2 video present
KEY 2 VIDEO MISMATCH
KEY 2 video mismatch with output video standard
KEY 2 VIDEO MATCH
KEY 2 video matches output video standard
KEY 2 VIDEO TIMING OUT OF RANGE
KEY 2 timing is out of range (<-1 line with respect to PGM OUT)
KEY 2 VIDEO TIMING IN RANGE
KEY 2 timing is within range
OVERALL VIDEO TIMING OUT OF RANGE
At least one of the VIDEO TIMING OUT OF RANGE is true
OVERALL VIDEO TIMING IN RANGE
Opposite of OVERALL VIDEO TIMING OUT OF RANGE
TEMPERATURE FAILURE
FPGA temperature >= 80°C
TEMPERATURE OK
FPGA temperature < 80°C
VOLTAGE FAILURE
At least one of 1.0V, 2.5V or 3.3V is ±5% out of range
VOLTAGE OK
All voltages are within range
NETWORK INTERFACE DOWN
The network interface is down
NETWORK INTERFACE UP
The network interface is up
CF USAGE HIGH
Compact Flash capacity >= 80%
CF USAGE OK
Compact Flash capacity < 80%
BACKPLANE LOSS
Backplane is not connected
BACKPLANE PRESENT
Backplane is present
MIXER AT A
AB Mixer is at A
MIXER AT B
AB Mixer is at B
DSK1 FTB OFF
DSK1 Fade-to-Black is Off
