GUIDE TO INSTALLATION AND OPERATION
LGK-3901/DSK-3901 | 107
Front Panel Menu Name LGK DSK Description
LINEAR › See “DSK 1” (above)
SENSE ›
NORMAL › See “DSK 1” (above)
INVERT › See “DSK 1” (above)
MASKING ›
DISABLE › See “DSK 1” (above)
SETUP › See “DSK 1” (above)
C, G & T › See “DSK 1” (above)
CUT TO/FR BLK › See “DSK 1” (above)
CUT FROM BLK › See “DSK 1” (above)
CUT TO BLK › See “DSK 1” (above)
FADE TO/FR BLK › See “DSK 1” (above)
FADE FROM BLK › See “DSK 1” (above)
FADE TO BLK › See “DSK 1” (above)
FTB RATE › See “DSK 1” (above)
INPUT OPS ›
FILL-1/KEY-1 › See “DSK 1” (above)
FILL-2/KEY-2 › See “DSK 1” (above)
UNLOAD INPUT › See “DSK 1” (above)
STORE OPS ›
LOAD IMAGE › See “DSK 1” (above)
SET POSITION › See “DSK 1” (above)
SAVE IMAGE › See “DSK 1” (above)
UNLOAD IMAGE › See “DSK 1” (above)
LOAD MODE ›
CLEAN LOAD › See “DSK 1” (above)
CUT LOAD › See “DSK 1” (above)
START STRAP › See “DSK 1” (above)
STOP STRAP › See “DSK 1” (above)
START TIMER › See “DSK 1” (above)
STOP TIMER › See “DSK 1” (above)
RESET TIMER › See “DSK 1” (above)
PLAY ANIMATION › See “DSK 1” (above)
RESTART ANIM › See “DSK 1” (above)
STOP ANIMATION › See “DSK 1” (above)
STOP ANIM NOW › See “DSK 1” (above)
PREVIEW OUTPUT › ›
PREVIEW O/P › › [4.9.2] Selects default Preview Output (see PREVIEW INPUT)
PROGRAM O/P › › [4.9.2] Selects a copy of PGM OUT as the Preview Output
PGM AB MIX › › [4.9.2] Selects output from PGM AB Mixer as the Preview Output
PGM DSK1 O/P › › [4.9.2] Selects output from PGM DSK1 as the Preview Output
PGM DSK2 O/P › [4.9.2] Selects output from PGM DSK2 as the Preview Output
PGM DSK3 O/P › [4.9.2] Selects output from PGM DSK3 as the Preview Output
PGM DSK4 O/P › [4.9.2] Selects output from PGM DSK4 as the Preview Output
SDI PGM IN › › [4.9.2] Selects a copy of SDI PGM IN as the Preview Output
SDI FILL-1 › › [4.9.2] Selects a copy of SDI FILL-1 as the Preview Output
SDI KEY-1 › › [4.9.2] Selects a copy of SDI KEY-1 as the Preview Output
SDI FILL-2 › › [4.9.2] Selects a copy of SDI FILL-2 as the Preview Output
SDI KEY-2 › › [4.9.2] Selects a copy of SDI KEY-2 as the Preview Output
STORE 1 FILL › [4.9.2] Selects the fill signal of Store 1 as the Preview Output
STORE 1 KEY › [4.9.2] Selects the key signal of Store 1 as the Preview Output
STORE 2 FILL › [4.9.2] Selects the fill signal of Store 2 as the Preview Output
STORE 2 KEY › [4.9.2] Selects the key signal of Store 2 as the Preview Output
