Grass Valley EDIUS Pro v.7.20 User Manual
Page 480
Interaction with STRATUS
458
EDIUS - Reference Manual
2 Click the [Source] tree, and click [Register K2 Asset].
3 Set each item.
4 Click [OK].
You can continue to set other items by clicking [Apply].
Loading K2 Clip Files to Be Managed by the K2 Media Server
3
•
While another EDIUS client on the same network is capturing a source in K2 Clip format, edit while recording
can be performed by loading the captured data.
• Edit lists in Program/List format are loaded as sequence clips.
1
Note
• You cannot load an edit list in Program/List format in the following conditions:
- The frame rate is different from that of the EDIUS project file.
- No valid clip exists in the Program/List data.
- The Program/List data is in invalid video format.
- Generating video/audio tracks or setting the channel map has failed while loading a clip.
- The Program data is being recorded.
• The following information contained in the Program/List data cannot be reproduced with EDIUS.
- The Repeat setting contained in List and Section under List
- The Stop setting contained in List, Section under List, and Event under Section
• When loading an edit list in Program/List format, the system will not load audio tracks that exceed the number of
channels in the project settings.
[Destination Server]
Click the list to display the list of the K2 Media servers of the connection des-
tination.
Select the default K2 Media server when transferring clips to the K2 Media
server.
[Destination Bin]
[Destination Path]
Display the path of the export destination.
The settings made in [Base Bin] and [Create Bin] are applied.
[Base Bin]
Select the bin to be the base of the export destination from the list.
[Create Bin]
Check this item to add a bin to a location selected in [Base Bin].
Select one of the bin names from the [Template] list which includes names
consisting of [{User Name}]/[{Date}]/[{Project Name}]/[{Custom}] in different
combinations. If you select [{Custom}], enter desired characters in [Custom].
[Clip Name Prefix]
Set the prefix to add on clip names.
Select one of the prefixes from the [Template] list which includes names con-
sisting of [{User Name}]/[{Date}]/[{Project Name}]/[{Custom}] in different com-
binations. If you select [{Custom}], enter desired characters in [Custom].
If a prefix is not necessary, select [{Custom}] and leave [Custom] blank.
[Register selected clips as K2
Program]
Check this item to register clips in the same format as a single K2 Program
format clip to the bin on the K2 Media server when selecting and exporting
multiple clips.
(This is valid only when the frame rate and field order of all clips are the
same.)
[Register K2 Asset material to Bin
when registering material from
Bin to K2 Asset.]
Check this item to register K2 Clip format clips, which have been exported
from the bin to the K2 Media server, to the bin of EDIUS.
[Register K2 Asset material to Bin
when registering material from
Source Browser to K2 Asset.]
Check this item to register K2 Clip format clips, which have been exported
from the source browser to the K2 Media server, to the bin of EDIUS.
