4 Click the Diagonal Take icon or select Diagonal Take from the context menu. The ‘Diagonal
Take’ dialog appears.
5 In the ‘Input’ section, enter a starting input number.
6 If you made an output selection (in step 3), the dialog appears with suggested values that
are based on your selection. You can leave the ‘Use Selection’ check box checked and the
range take will apply to your selection.
Otherwise, enter a range of outputs In the ‘Output’ section. The range of valid destinations
appears at the right. Enter a starting number in the left-hand field and an ending number in
the right-hand field. All outputs in that range are selected.
7 (Optional) Check the Reverse check box to perform a reverse diagonal take.
A diagonal take counts inputs upward from the starting point.
A reverse diagonal take counts inputs downward from the starting point.
