159
Miranda Router Configurator
User’s Guide
Extended status data are not available for any other modules. MRC reports “N/A.”
Video Formats
These are the (identifiers for the) video formats accepted by the NV8500 routers:
If MRC does not recognize the video format, it reports “unknown.”
IOXM Extended Status Reporting
Following are the data reported for various module types:
Standard Input
Path Light (whether the module’s path light is on).
Rear (whether the backplane module in the slot is present and appropriate for the module).
Temperature (8-bit value in degrees centigrade).
Input carrier detect (a 9-bit string of 1s and 0s, one bit for each input, indicating whether a signal
is present at the input).
Standard Output
Path Light
Rear
Temperature
Output Reclocker (an 18-bit string of 1s and 0s, one bit for each output).
 “Output reclocker” simply means that there is video present at the output. There is no rela-
tionship in this status field to reclockers or to the bypass flags found in the ‘Output
Attributes’ page.
Hybrid Output
Path Light
Rear
Temperature
Output Reclocker (in the bit string, bits 9 and 18 are always 0).
Video rate and format for each output. Outputs 9 and 18 are of course reported as “N/A.”
EM0895 Standard 144×144 redundant crosspoint, 3Gig, for NV8140
EM0896 Standard 288×288 crosspoint, 3Gig
720p60, 720p59.94, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 720p50
1080i60, 1080i59.94, 1080i50, 1080i48
1080p25, 1080p30, 1080p29.97, 1080p60, 1080p59.94, 1080p50, 1080p24, 1080p23.98
525i59.94 (NTSC), 625i50 (PAL)
Crosspoints
