Grass Valley MRC v.1.2 - Manual (Page 121)

111
Miranda Router Configurator
User’s Guide
Creating and Updating a Salvo
Salvos can be created at any time and saved for later use.
To create a salvo, click the Salvo button . . .
or click ‘Create Salvo’ in the context menu.
There are two kinds of results that you can expect when you create a salvo:
• If you have two or more rows selected in the displayed crosspoint matrix, the new salvo
includes just those rows.
• If you have one row or no rows selected, the salvo becomes a complete copy of the dis-
played crosspoint matrix.
You can make changes to a salvo without affecting the router’s crosspoint matrices in any way.
You can add rows to a salvo and delete rows from a salvo.
How to Create or Update a Salvo
1 Go to the ‘Crosspoints’ page. From the Control Cards table, at the bottom of the page, select
a control card.
2 Either create a new salvo . . .
To create a salvo, click the Salvo button . . .
or click ‘Create Salvo’ in the context menu.
3 . . . or open an existing salvo.
Click an existing ‘Salvo’ tab.
Or, click Open Salvo, at the bottom of the page. In the ‘Open’ dialog that appears, browse to
locate a salvo file and select the file. Click Open. The opened salvo will appear in a new
‘Salvo’ tab.
Create Salvo Creates, and opens, a new ‘Salvo’ tab displaying a “snapshot” of the
crosspoint matrix that is open in the ‘Current’ tab.
See Creating and Updating a Salvo on page 111.
Save As Salvo Saves the crosspoint data in the ‘Salvo’ tab as a salvo file for later use.
This command performs the same function as the Save As Salvo button
at the bottom of the Crosspoints page.
See Creating and Updating a Salvo on page 111.
Command Icon Description
