13.1 Graphics
13
320
TNC 128 | User's Manual HEIDENHAIN Conversational Programming | 5/2014
Overview: Display modes
In the
Program Run, Single Block and Program Run, Full
Sequence operating modes as well as in the Test Run operating
mode, the TNC displays the following soft keys:
View Soft key
Plan view
Projection in three planes
3-D view
The position of the soft keys depends on the
selected operating mode.
The
Test Run operating mode additionally offers the following
views:
View Soft key
Volume view
Volume view and tool paths
Tool paths
Limitations during program run
The result of the simulation can be faulty if the TNC's
computer is overloaded with complicated processing
tasks.
