254 Programming: Q Parameters
8.8 A
d
ditional F
unctions
5 - Tool data programmed in TOOL DEF
1 = yes, 0 = no
Active tool compensation, 200 1 1 = without oversize
2 = with oversize
3 = with oversize and
oversize from
TOOL CALL Active radius
2 1 = without oversize
2 = with oversize
3 = with oversize and
oversize from
TOOL CALL Active length
3 1 = without oversize
2 = with oversize
3 = with oversize and
oversize from
TOOL CALL Rounding radius R2
Active transformations, 210 1 - Basic rotation in MANUAL OPERATION mode
2 - Programmed rotation with Cycle 10
3 - Active mirrored axis
0: mirroring not active
+1: X axis mirrored
+2: Y axis mirrored
+4: Z axis mirrored
+64: U axis mirrored
+128: V axis mirrored
+256: W axis mirrored
Combinations = sum of individual axes
4 1 Active scaling factor in X axis
4 2 Active scaling factor in Y axis
4 3 Active scaling factor in Z axis
4 7 Active scaling factor in U axis
4 8 Active scaling factor in V axis
4 9 Active scaling factor in W axis
5 1 3-D ROT A axis
5 2 3-D ROT B axis
Group name, ID no. Number Index Meaning
