HEIDENHAIN TNC 320 329
1
0
.2 W
o
rk
ing with the P
a
ra
llel Ax
es U
, V and W
Move the principal axis and the parallel axis simultaneously
If the PARAXMODE function is active, the TNC uses the axes defined in
the function to execute the programmed traverse movements. If the
TNC is to traverse a parallel axis simultaneously with the associated
principal axis, you can identify the respective axis by additionally
entering the character "&". The axis with the & character then refers to
the principal axis. Example: NC block
13 FUNCTION PARAXMODE X Y W
14 L Z+100 &Z+150 R0 FMAX
The syntax element "&" is only permitted in L blocks.
Additional positioning of a principal axis with the "&"
command is done in the REF system. If you have set the
position display to "actual value", this movement will not be
shown. If necessary, switch the position display to "REF
value".
