28
SPECIFICATIONS
Cabinet:
Outdoor – Plastic, weather-resistant, indoor/outdoor, wall mount
with key-actuated locking cover
Indoor – Durable plastic cabinet with an external transformer.
Dimensions:
Outdoor – 10.5" W x 8.375" H x 5" D
(26.67cm W x 21.27cm H x 12.7cm D)
Indoor – 9.5" W x 7.5" H x 4.25" D
(24.13cm W x 19.05cm H x 10.8cm D)
Wiring/Conduit Provision:
Power Wiring – 1/2" NPT nipple
Field Wiring – 1-1/2" (38mm) diameter conduit access
Power Specifications, Domestic Outdoor/Indoor Model:
Input – 120 V a.c., 60 Hz, 0.5A
Output – 24 V a.c., 60 Hz, 1.25A (max. total),
0.5A (max. per station)
Power Specifications, International Outdoor/Indoor Model:
Input – 230 V a.c., 50 Hz, 0.5A
Output – 24 V a.c., 50 Hz, 1.25A (max. total),
0.5A (max. per station)
Power Specifications, Australian Outdoor/Indoor Model:
Input – 240 V a.c., 50 Hz, 0.5A
Output – 24 V a.c., 50 Hz, 1.25A (max. total),
0.5A (max. per station)
Sensor Input, Outdoor/Indoor Model:
Normally-closed rain switch (override switch provided)
Master Valve/Pump Start Relay Output, Outdoor/Indoor Model:
24 V a.c., 0.5A (maximum)
Battery: 9-volt, Alkaline
Fuse: 250V, 2A, Slow-Blow
Temperature Limit Specifications:
Operating – 32°F to 140°F (0°C to 60°C)
Storage – -22°F to 149°F (-30°C to 65°C)
Specifications
