Figure 20. Measuring Voltage.
AC VOLTAGE MEASUREMENT
1) Set the rotary switch to “ V ”.2) Insert the black test lead to “COM” terminal and red test lead to
“ V
Ω
terminal.
3) Touch the probes to the test points and read the displayed AC voltage.
