5 Mega-pixel Outdoor IR PoE IP Camera
User’s Manual of ICA-3550V
System Integration
Application Programming
Interface Open API for software integration
SDK
Alarm Triggers
Intelligent video motion detection and external input
3-zone video motion detection
Alarm Events
File upload via FTP, email and SAMBA.
External output activation
Configurable Pre/Post alarm buffering
General
Power Supply 12V DC, 1A
IEEE 802.3af Class 0
Power Consumption
DC 12V Max: 6.48W(IR On); 4.2W(IR Off)
PoE Max: 8.16W (IR on); 5.28W(IR Off)
Housing Weather-proof IP66-rated housing
Operating Temperature -20 ~ 50 degrees C
Operating Humidity 20 ~ 80% (non-condensing)
Weight 1062g
Dimensions (Φ x L) 83mm x 180 mm
Emission CE, FCC
Connectors
10/100 Mbps Ethernet, RJ-45
DC power jack
Terminal block for 1 alarm input , 1 output and factory default reset
External mic input
Audio out
Micro SD/SDHC card (max 32GB, class 6)
Composited video out
1.3 Package Contents
The package should contain the following:
ICA-3550V x 1
Power Adapter x 1
Screw Package x 1
Female to Female RJ-45 Connector x 1
User’s Manual CD x 1
Quick Installation Guide x 1
1. If any of the above items are missing, please contact your dealer immediately.
2. Using the power supply that is not the one included in the Internet Camera packet will
cause damage and void the warranty for this product.
