User’s Manual of ICA-3550V
2.3 Hardware Installation
2.3.1 Physical Installation
1. Connect an Ethernet cable
Connect the LAN cable on the camera to the network device (hub or switch).
If there is an IEEE802.3af PoE switch in your network, you can connect the camera LAN cable to
this PoE switch to obtain power. The power adapter is unnecessary when Internet camera is
connected to a PoE switch.
2. Attach the power supply
Plug the power adapter into a power source. After power is on, the camera will start to operate.
1. Only use the power adapter supplied with Internet camera. Otherwise, the product may
be damaged.
2. The power adapter is unnecessary when Internet camera is connected to a PoE switch.
Otherwise, the product may be damaged when Internet camera is connected to a PoE
switch and power adapter simultaneously.
3. Attach BNC connector
Connect the video BNC connector to a monitor set if necessary and check camera viewing angle
and focus.
4. Attach speaker to camera (optional)
If user needs not only video stream but also audio stream, then the speaker should be attached to
the camera.
18
