Command Entry Formats
The following table shows the structure of the configuration data necessary for
each of the supported commands.
MNET MODBUS Command Structure
Column
#
1 2 3 4
5
6 7
8 9 10
Function
Code
Enable
Code
Internal
Address
Poll
Interval
Time
Count Swap
Code
IP
Address
Serv
Port
Slave
Node
Function
Code
Device
Modbus
Address
fc1 Code
Register
1/10th
Seconds
Count 0
IP
Address
Port # Address
1
Register
fc2 Code
Register
1/10th
Seconds
Count 0
IP
Address
Port # Address
2
Register
fc3 Code
Register
1/10th
Seconds
Count Code IP
Address
Port # Address
3
Register
fc4 Code
Register
1/10th
Seconds
Count Code IP
Address
Port # Address
4
Register
fc5 Code
Register
1/10th
Seconds
Count 0
IP
Address
Port # Address
5
Register
fc6 Code
Register
1/10th
Seconds
Count 0
IP
Address
Port # Address
6
Register
fc15 Code
Register
1/10th
Seconds
Count 0
IP
Address
Port # Address
15
Register
fc16 Code
Register
1/10th
Seconds
Count Code IP
Address
Port # Address
16
Register
The first part of the record is the Module Information, which relates to the ProLinx
module and the second part contains information required to interface to the
Server device.
Command list example:
